ITEM |
SP-32L |
SP-36L |
SP-40L |
||
|
Max swing over bed |
Φ360mm |
Φ420mm |
Φ450mm |
||
|
Max swing over carriage |
Gang Φ110mm; Turret Φ130mm |
Φ130mm |
Φ180mm |
||
|
Max turning diameter |
Φ320mm |
Φ360mm |
Φ400mm |
||
|
Max processing length |
Gang 300mm; Turret 220mm |
Gang 260mm; Turret 180mm |
Gang 370mm; Turret 270mm |
Gang 350mm; Turret 250mm |
Gang 300mm; Turret 200mm |
|
X axis travel |
380mm |
470mm |
|||
|
Z axis travel |
330mm |
400mm |
|||
|
X axis ball screw |
2510-C3 |
3210-C3 |
|||
|
X motor torque |
≥7.5nm |
≥7.5nm |
|||
|
Z axis ball screw |
3210-C3 |
3210-C3 |
|||
|
Z motor torque |
≥7.5nm |
≥10nm |
|||
|
Bed slant angle |
45 ° |
45 ° |
|||
|
Linear guide’s span |
362mm |
440mm |
|||
|
Max spindle speed |
4500rpm |
4500rpm |
4500rpm |
3000rpm |
|
|
Spindle bore |
Φ46mm |
Φ56mm |
Φ56mm |
Φ61mm |
Φ79mm |
|
Spindle nose size |
A2-4 |
A2-5 |
A2-5 |
A2-6 |
A2-6 |
|
Spindle bore taper |
|||||
|
Spindle motor |
3.7kw or 5.5kw |
5.5kw |
5.5kw |
7.5kw |
7.5kw |
|
Hydraulic or collet chuck |
5″ hydraulic or Φ36mm collet chuck |
6″ hydraulic or Φ46mm collet chuck |
6″ hydraulic or Φ46mm collet chuck |
8″ hydraulic or Φ52mm collet chuck |
10″ hydraulic |
