ITEM |
SP-22L |
SP-28L |
|
Max swing over bed |
Φ300mm |
Φ320mm |
|
Max swing over carriage |
Gang Φ90mm |
Gang Φ90mm; Turret Φ100mm |
|
Max turning diameter |
Φ220mm |
Φ280mm |
|
Max processing length |
Gang 200mm |
Gang 200mm; Turret 120mm |
|
X axis travel |
250mm |
320mm |
|
Z axis travel |
250mm |
250mm |
|
X axis ball screw |
2510-C3 |
2510-C3 |
|
X motor torque |
/ |
≥6nm |
|
Z axis ball screw |
2510-C3 |
2510-C3 |
|
Z motor torque |
/ |
≥6nm |
|
Bed slant angle |
45 ° |
45 ° |
|
Linear guide’s span |
290mm |
320mm |
|
Max spindle speed |
4500rpm |
4500rpm |
|
Spindle bore |
Φ28mm |
Φ36mm |
|
Spindle nose size |
/ |
A2-4 |
|
Spindle motor |
2.2kw |
3.7kw |
|
Hydraulic or collet chuck |
Φ20mm collet chuck |
5″ hydraulic or Φ25mm collet chuck |
