Max Swing Over Bed: 140mm
Distance Between Centers: 250mm
Spindle Power: 150W
|
Model |
SP2138 |
|
Swing over Bed |
140 mm |
|
Swing over Carriage |
75 mm |
|
Distance Between Centers |
250 mm |
|
Maximum Travel on X Axis |
100 mm |
|
Motor Torque of X Axis |
1.35 N·m |
|
Maximum Travel on Z Axis |
150 mm |
|
Motor Torque of Z Axis |
1.35 N·m |
|
Spindle Bore |
10 mm |
|
Spindle Taper |
MT2 |
|
Spindle Speed |
100 – 2,000 rpm |
|
Tailstock Taper |
MT1 |
|
Tool Post Position |
2 |
|
Motor Power |
150 w |
|
Voltage and Frequency |
Customerized |
|
Overall Dimensions (LxWxH) |
730 x 380 x 350 mm |
|
Packing Size (LxWxH) |
830 x 480 x 450 mm |
|
Net Weight |
45 kg |
|
Gross Weight |
60 kg |
