SP2307 |
|
|
Swing dia. over bed |
330mm |
13″ |
|
Swing dia. over table |
190mm |
7.5″ |
|
Distance between centers |
610mm/1000mm |
24″40″ |
|
Spindle bore |
28mm |
1.1″ |
|
Spindle speed |
50～3000r/min |
|
|
Longitudinal stroke |
510mm/890mm |
20″/35″ |
|
Cross stroke |
185mm |
7.3″ |
|
Small toolpost stroke |
70mm |
2.75″ |
|
Metric pitch/grade |
0.35～6.5mm/24 |
|
|
Inch pitch/grade |
7～52T.P.I./21 |
|
|
Longitudinal feed/grade |
0.067～0.5mm/r/21 |
|
|
Cross feed/grade |
0.021～0.157mm/r/21 |
|
|
Milling-drilling spindle taper |
MT3 |
R8 |
|
Milling-drilling shaft stroke |
127mm |
5″ |
|
Milling-drilling box stroke |
110mm |
4.33″ |
|
Table size |
450×170mm |
17.7″×6.7″ |
|
Drilling dia. |
24mm |
0.95″ |
|
Power of motor |
1.1kw |
|
|
Case dimensions of machine |
1260×570×1110mm/1640×570×1110mm |
|
|
Case dimensions of stand |
1540×560×550MM |
|
|
Net/aross weight of the machine |
330/380kg |
|
