SPECIFICATIONS |
Metric |
Inch |
|
Longitudinal stroke |
340mm |
14 |
|
cross strock |
170mm |
7 |
|
vertical strock |
210mm |
8 |
|
Table size |
152mm×304mm |
6×12 |
|
Width of T-slot |
1-12mm |
1-0.47 |
|
Cross feed per graduation |
0.02mm |
0.001 |
|
Cross feed per round |
2.54mm |
0.1 |
|
Vertical feeds per graduation |
0.025mm |
0.001 |
|
Vertical feed per round |
1.25mm |
0.05 |
|
Roughness |
1.6μm |
|
|
Size fo grinding wheel |
180mm×32mm×13mm |
|
|
Power of motor |
0.55kw |
|
|
N. W. / G.W.of machine |
210/258kg |
|
|
N. W. / G.W.of stand |
30/54kg |
|
|
Overall dimension of machineL×W×H |
930×780×730mm |
|
|
Case dimension of machineL×W×H |
1100×760×860mm |
|
|
Case dimension of standL×W×H |
750×580×630mm |
|
