SP5020 Slotting Machine

>> The working table of the machine tool is provided with three different directions of feed (longitudinal, horizontal and rotary), therefore work object go through once clamping, Several surfaces in the machine tool machining

>> Hydraulic transmission mechanism with sliding pillow reciprocating motion and hydraulic feed device for working table.

>> The sliding pillow has the same speed in every stroke, and the movement speed of the ram and the working table can be adjusted continuously.

>> Hydraulic control table have ram commutation oil for oil reversing mechanism, In addition to hydraulic and manual feed outer, Even there single motor drive vertical, horizontal and rotary fast moving.

>>Use hydraulic feed the slotting machine, Is when the work is over turning back instantaneous feed, Therefore be better than mechanical slotting machine used drum wheel feed.

Application: >> This machine be used for interpolation plane, forming surface and Keyway Etc. And can insert the inclination in the 10° Mold and other within the scope of etc. work matter,, >> Enterprise suitable for single or small batch production.

Model	SP5020
Max.slotting length	200mm
Max.dimensions of wodplece(L*H)	485*220mm
Power of rapid drive motor	3kw
Rotating speeed of main drive motor	1430r.p.m
Max.weight of workpiece	400kg
No.of strokes per minutem	32.50.80.125.r.p.m
Distance between tool holdingsurface and column front	485mm
Max.tool shank size (W*H)	25*40mm
Table diameter	500mm
Distance between table surface and low end of ram	320mm
Max.longitudinal travel of table	400/450mm
Max.cross travel of table	450/500mm
Max.Rotary angle of table	±360 degree
Overall dimensions (LWH)	138513051995mm
Weight(approx)	2400kg
