Maximum cutting diameter of vertical tool post:1600mm
Diameter of worktable:1400mm
Maximum processing height:1000mm
Main motor power:30Kw
|
Specifications |
SP5116CNC |
Unit |
|
Maximum cutting diameter of vertical tool post |
1600 |
mm |
|
Diameter of worktable |
1400 |
mm |
|
Maximum processing height |
1000 |
mm |
|
Maximum weight of workpiece |
5 |
t |
|
Rotating speed range of worktable |
5-160 |
r/min |
|
Rotating speed of worktable |
Four step various speed |
Step |
|
Maximum torque of worktable |
25 |
Kn/m |
|
Feed level of tool post |
Various speed |
Step |
|
Maximum cutting force of vertical tool post |
25 |
KN |
|
Ram |
915 |
mm |
|
800 |
mm |
|
|
Beam stroke |
850 |
mm |
|
Fast moving speed of tool post |
2000 |
mm/min |
|
Beam lifting speed |
580 |
mm/min |
|
Tool bar section size (length×width) |
30×40 |
mm |
|
Main motor power |
30 |
kW |
|
System Configuration |
Siemens 828D system |
|
|
CNC axis |
X.Z two-axis linkage |
|
|
Positioning accuracy |
0.03 |
mm |
|
Repeatability |
0.015 |
mm |
|
Machining dimensional accuracy |
IT7 |
|
|
Machine weight (approximately) |
13 |
t |
