Maximum Cutting Length(mm): 1000mm
Dimensions of Table Top(L×W): 1000*500mm
Max. Swivel Angle of the Toolhead：±60°
|
Model |
SP60100 |
|
Maximum cutting length (mm) |
1000 |
|
Maximum distance from ram bottom to table surface (mm) |
400 |
|
Maximum table horizontal travel (mm) |
800 |
|
Maximum table vertical travel (mm) |
380 |
|
Dimensions of table top surface（ L×W） (mm) |
1000×500 |
|
Travel of tool head (mm) |
160 |
|
No. of ram strokes per minute |
15、20、29、42、58、83 |
|
Swivel of tool head (°) |
±60° |
|
Max. size of tool shank（W×T）(mm) |
30×45 |
|
Range of table power feed – horizontal |
0.3-3mm 10steps |
|
Range of table power feed – vertical |
0.15-0.5mm 8step |
|
Width of central T-slot of table (mm) |
22 |
|
Power of motor (kw) |
7.5 |
|
Overall dimensions （L×W×H）(mm) |
3640×1575×1780 |
|
Weight（kg） |
4870 |
