Maximum Cutting Length(mm): 500/660/850mm
Dimensions of Table Top(L×W): 440×360/660X400/800X450mm
Max. Swivel Angle of the Toolhead：±60°
|
Model |
SP6050 |
SP6066 |
SP6085 |
|
|
Maximum cutting length(mm) |
500 |
660 |
850 |
|
|
Max.range horizontal movement of the table |
500 |
660 |
710 |
|
|
Max.distance between the ram bottom and table |
370 |
385 |
400 |
|
|
Max.length of the vertical movement of table |
270 |
360 |
360 |
|
|
Dimensions of table top(L×W) |
440×360 |
660X400 |
800X450 |
|
|
Max.stroke length of the toolhead |
120 |
120 |
160 |
|
|
Max.swivel angle of the toolhead |
±60° |
±60° |
±60° |
|
|
Max.section of tool(W×T)(mm) |
20×30 |
20×30 |
/ |
|
|
Number of ram reciprocation per minute |
14-80 |
14-80 |
17-100 |
|
|
Range of table feed: |
horizontal |
0.2-0.25 |
0.4-5.0 |
0.25-3 |
|
Vertical |
0.08-1.00 |
0.08-1.00 |
0.12-1.5 |
|
|
Width of the T-slot(mm) |
18 |
18 |
22 |
|
|
Power of the main motor |
3 |
3 |
5.5 |
|
|
N.W/G.W(kg) |
1650/1760 |
1800/1920 |
2940/3090 |
|
|
Overall dimensions(L×W×H)(mm) |
2160×1070×1194 |
2357×1225×1480 |
2950x1325x1693 |
|
