Maximum Cutting Length(mm): 630/660mm
Dimensions of Table Top(L×W): 630*400mm
Max. Swivel Angle of the Toolhead：±60
|
Model |
SP6063/SP6066 |
|
Maximum cutting length(mm) |
630/660 |
|
Maximum distance from ram bottom to table surface(mm) |
385 |
|
Maximum table horizontal travel(mm) |
630 |
|
Maximum table vertical travel(mm) |
360 |
|
Dimensions of table top surface(L×W)(mm) |
630×400 |
|
Travel of tool head(mm) |
120 |
|
Number of ram strokes per minute |
14、20、28、40、56、80 |
|
Swivel of tool head(°) |
±60° |
|
Maximum size of tool shank(W×T)(mm) |
20×30 |
|
Range of table power feed （horizontal） |
0.2~2.5 (12 steps) |
|
Range of table power feed （vertical） |
0.08~1.00(12 steps) |
|
Width of central T-slot of table(mm) |
18 |
|
Power of mortr(kw) |
3 |
|
Overall dimensions(L×W×H)(mm) |
2342×1225×1480/2357×1225×1480 |
|
N.W/G.W(kg) |
1750/1870 |
