ITEM |
SP-630 |
SP-800 |
|
Max swing over bed |
Φ630mm |
Φ800mm |
|
Max swing over carriage |
Φ300mm |
Φ360mm |
|
Max turning diameter |
Φ600mm |
Φ700mm |
|
Max processing length |
1000mm |
800mm |
|
X axis travel |
350mm |
350mm |
|
Z axis travel |
1100mm |
1100mm |
|
X axis ball screw |
4010-C3 |
4010-C3 |
|
X motor torque |
≥15nm |
≥15nm |
|
Z axis ball screw |
4010-C3 |
4010-C3 |
|
Z motor torque |
≥15nm |
≥15nm |
|
Bed slant angle |
45 ° |
45 °one whole iron cast |
|
Linear guide’s span |
466mm |
466mm |
|
Max spindle speed |
3000rpm |
1500rpm |
|
Spindle bore |
Φ88mm |
Φ105mm |
|
Spindle nose size |
A2-8 |
A2-11 |
|
Spindle bore taper |
1:20 |
1:20 |
|
Spindle motor |
15kw |
22kw |
|
Hydraulic or collet chuck |
12″ hydraulic |
15″ hydraulic |
|
Diameter of tailstock sleeve |
Φ90mm |
Φ90mm |
|
Max travel of tailstock sleeve |
120mm |
120mm |
|
Taper of tailstock sleeve |
MT5 |
MT5 |
