Max swing over bed:420mm/420mm/450mm
|
ITEM |
SP-340 |
SP-360 |
SP-400 |
|||
|
Max swing over bed |
Φ380mm |
Φ420mm |
Φ420mm |
Φ450mm |
||
|
Max swing over carriage |
Φ130mm |
Φ160mm |
Φ160mm |
Φ160mm |
Φ220mm |
Φ220mm |
|
Max turning diameter |
Φ340mm |
Φ340mm |
Φ340mm |
Φ360mm |
Φ400mm |
Φ400mm |
|
Max processing length |
280mm |
250mm |
200mm |
500mm |
450mm |
400mm |
|
X axis travel |
180mm |
250mm |
||||
|
Z axis travel |
330mm |
530mm |
||||
|
X axis ball screw |
3208-C3 |
3208-C3 |
||||
|
X motor torque |
≥7.5nm |
≥10nm |
||||
|
Z axis ball screw |
3210-C3 |
3208-C3 |
||||
|
Z motor torque |
≥10nm |
≥10nm |
||||
|
Bed slant angle |
45 ° |
45 ° |
||||
|
Linear guide’s span |
362mm |
400mm |
||||
|
Max spindle speed
|
4500rpm
|
4500rpm
|
4500rpm
|
4500rpm
|
4500rpm
|
3000rpm
|
|
Spindle bore
|
Φ46mm
|
Φ56mm
|
Φ61mm
|
Φ56mm
|
Φ61mm
|
Φ79mm
|
|
Spindle nose size
|
A2-4
|
A2-5
|
A2-6
|
A2-5
|
A2-6
|
A2-6
|
|
Spindle bore taper
|
|
|
|
|
|
|
|
Spindle motor
|
5.5kw
|
5.5kw
|
7.5kw
|
5.5kw
|
7.5kw
|
7.5kw
|
|
Hydraulic or collet chuck
|
5″ hydraulic or Φ36mm collet chuck
|
6″ hydraulic or Φ46mm collet chuck
|
8″ hydraulic or Φ52mm collet chuck
|
6″ hydraulic or Φ46mm collet chuck
|
8″ hydraulic or Φ52mm collet chuck
|
10″ hydraulic
|
|
Diameter of tailstock sleeve
|
Φ72mm
|
Φ72mm
|
Φ72mm
|
Φ72mm
|
Φ72mm
|
Φ72mm
|
|
Max travel of tailstock sleeve
|
100mm
|
100mm
|
100mm
|
100mm
|
100mm
|
100mm
|
|
Taper of tailstock sleeve
|
MT4
|
MT4
|
MT4
|
MT4
|
MT4
|
MT4
|
