Max Drilling capacity：16mm
Motor power：550W
Spindle Travel：80mm
Table Size：240×245mm
|
Model |
SP5216VS80 |
|
Motor |
550w |
|
Column diameter |
65mm |
|
Swing |
305mm |
|
Max.drilling capacity |
16mm |
|
Chuck capacity |
16mm |
|
Taper |
B16 |
|
Spindle travel |
80mm |
|
No. of speed |
Variable |
|
Speed range 50Hz |
450-2500rpm |
|
Speed range 60Hz |
530-3100rpm |
|
Table size |
240*245mm |
|
Base size |
395*250mm |
|
Overall height |
920mm |
|
Measurement-Carton |
750*500*280mm |
|
N.W/G.W |
35/33kg |
|
Model |
SP5216VS/90 |
|
Drilling capacity |
16mm |
|
Chuck capacity |
16mm |
|
Swing |
12’’(300mm) |
|
Spindle taper |
MT2 |
|
Speed range(50Hz) |
360-3500 |
|
Speed range(60Hz) |
450-4000 |
|
Spindle travel |
90 |
|
Column diameter |
59.5mm |
|
Rack& pinion |
Yes |
|
Base size |
413*246mm |
|
Table size |
243*243mm |
|
Motor |
550W |
|
Overall Height |
910mm |
|
N.W/G.W |
43/46kg |
|
Packing size |
700*510*270mm |
|
Units per 20’ container |
300 pcs |
|
Model |
SP5216VS/150 |
|
Max drill diameter |
16mm |
|
Spindle speed |
500-2000rpm variable speed |
|
Spindle travel |
150mm |
|
Swing |
430mm |
|
Spindle Taper |
MT2 |
|
Height |
1820mm |
|
Motor power |
1100W |
|
Column diameter |
80mm |
|
Table size |
356x356mm |
|
Base table size |
252x210mm |
|
N.W./G.W. |
105/95kgs |
|
Packing size |
1530x700x280mm |
|
20GP container |
88sets |
|
Included |
LED, LASER, Chuck guard |
